12S JST-XH Balance Board
This balance board allows you to take full advantage of the 12S capabilities of the iCharger X12.
Easily connect packs up to 12S that have split balance leads (6S + 6S, for example), or just use it as a breakout board for 3S-6S packs to add some flexibility to your charging setup.
| Input Connector (Board) | JST-XH: 3S x2, 4S x2, 5S x2, 6S x2 |
| Output Connector (Board) | 12S JST-XH |
| Input Connector (Cable) | 12S JST-XH |
| Length (Wire) | 6" |
| Wire Type | 22 AWG Silicone |
Balance Board Info SheetCustomer Reviews
I like the fact that the pins are numbered. This helps when changing multiple batteries. However the balance sockets are to close together to plug the battery balance plugs in side by side.
Thanks for the feedback, Conna! Not all batteries have those 'balance connector protectors', and I personally just remove mine as I find they get in the way, even when using other balance boards. We do also have the 'Series Balance Adapters' (part number AC-SBA) which don't have the issue of the connectors being too close together.
Hope this info helps!
Efficient delivery as always. Thanks guys
The 12s JST-XH blance boards are great they even came with leads. Well made and work as expected. A great product at a great price. Progressive rc has your back on your charging products you my need.
Awesome item does exactly what it’s designed to do, works perfectly.
I like the fact that this board is compact. The balance ports are arranged perfectly for my purposes other than the ports are slightly too close together to plug two packs in with balance tap protectors in place. For the most part, I am charging 10S. They configured as two 5 cell packs in series and have to be charged as a 10S pack (hard wired). This slight disparity is not a problem for me as I simply remove the tap protectors.
