4512DUO
This high power charger is capable of 45A per channel and up to 2800W total output
£333.00

There's a new top of the line charger out there: introducing the iCharger 4512Duo - capable of 45A charge rates and a mammoth total output of 2800W.

Upgraded top to bottom from its 4010Duo beginnings, the 4512Duo offers beefier connections on both the input and output in order to handle the higher current levels, and features the new open-port style balance connections that do away with the need for separate balance boards. There's also a beautiful new IPS display, improved temperature ports, a USB-C fast-charge port, and more!

Nothing beats an iCharger, and nothing beats the convenience of a dual-port charger. Two independent charging channels in one compact unit lets you simultaneously work with batteries of different cell count, charging at up to 45A per channel simultaneously - or if you want to go all out, combine the two channels and charge at up to 70A!



Read More
Read Less
Charge Power (Max) 2800W (2000W per channel)
Charge Current Range 0.1-45A per channel (80A in sync mode)
Discharge (Max) 200W (130W per channel)
External Discharge (Max) 2800W (2000W per channel)
Regenerative Discharge (Max) 2800W (2000W per channel)
Discharge Current Range 0.1-45A (80A in sync mode)
Balance Current 2A per channel
Maximum Output Voltage (Power Supply Mode) 55V DC
Input Voltage 11-53V DC
Input Current Limit 80A
Input Connector Female EC8 (female housing, male bullets)
Main Charge Connector Female XT90 (female housing, male bullets)
Balance Connector 12S JST-XH (open-port connection for 2S-12S)
Supported Battery Types LiPo/LiHV/Li-Ion/LiFe/LTO/NiZn: 1-12S; NiMH/NiCd: 1-32S; Pb: 1-20S
USB Charge Type-C Charge Port: 5V/3A, 9V/2A, 12V/1.5A
Warranty 1 year
Dimensions 210x140x80mm
Weight 1530g
