iCharger 4010Duo

4010DUO
High-power charger providing 40 amps on each of two channels - or combine the two outputs in parallel for up to 70 amp charge rates!

Includes a free JST-XH balance board for each channel!
$349.99

There's a new heavyweight in the ring: the iCharger 4010Duo. With two channels available, each of which can charge at up to 40 amps simultaneously, it's like having two superchargers in one. Or combine both channels in parallel to achieve up to 70 amp charge rates!

With two JST-XH balance boards thrown in for free - one for each channel - you'll be ready to go right away.

Read More
Read Less
Input Voltage 9 - 50V DC
Dimensions 210x140x80 mm
Balance Accuracy 10mV
Memories 64 user presets
Current Drain (Balancing) 1.2A per channel (up to 2.4A in synchronous mode)
Discharge Current Range 0.05-40A per channel (up to 70A in synchronous mode)
Input Current 65A
Temperature Control (Intel.) Yes
LiPo/LiIo/LiFe 1 - 10 series
Charge Power (Max) 2000W at >34V (1400W max. per channel)
Discharge (Max) 130W per channel (up to 200W in synchronous mode)
External Discharge (Max) 1600W per channel (up to 3200W in synchronous mode)
Regenerative Discharge (Max) 1400W per channel (up to 2000W in synchronous mode)
Cell Count (NiCd/NiMh) 1 - 25 series
Pb Battery Cell Count 1 - 18 series
PC Connectivity Mini USB 2.0
Warranty 1 year
Weight 1470g
Charge Current Range 0.05-40A per channel (up to 70A in synchronous mode)

Customer Reviews

Based on 47 reviews
74%
(35)
23%
(11)
0%
(0)
0%
(0)
2%
(1)
S
SHEHZAD KHAN
4010 Duo

Amazing Charger

J
Jim Workman
Review of iCharger 4010duo.

I race one cell 17.5 pan car. I love the fact that I can check the IR with this charger and the fact that I can discharge the packs at 30 Amps. This is an excellent charger for my racing program.

V
V.B.
the most powerful charger today

If using both channels - this is surely the most powerful charger to buy off-shelf. We can charge 20 cells at the same time in asynchronous mode (separately 10 cells per channel). Add to this the 48VDC meanwell power supply 2000W + quick advice over the phone from Chad => this is a super deal

R
Richard Bombash
4010 DUO

This is the second 4010Duo purchased from Progressive RC. Sent the first back for repair (fast turn around) but as I live overseas the shipping time is weeks not days for the round trip, and now await it's return. Have had nothing but great charging/discharging from both chargers. Charge 6s 5000 mah batteries all the time. Discharging them to storage charge gets the charger a little warm, but so far not warm enough to shut down. This one was bought so I wouldn't miss out on any flying. Would easily purchase a third if needed in the future.

H
H R Mickelson
Great until it quits

I would give this a 5, but for the repair situation on the 4010. Expensive, but good value for the money. Downside is a 6 to 13 month delay to get it repaired. My first 4010 lasted just short of 3 years and the buttons quit working on a storage operation. Elected to just buy another one due to the long unreasonable repair time. Icharger needs a US based repair center and I would be happy to do it as I have an full professional lab. But with no schematics and part numbers removed it is very difficult to repair anything other than the Caps and FETs. Failure in my case was in the control circuit. So now I have a boat anchor and a new running unit.
