TBS has pulled out all the stops with this latest VTX EVOlution

Introducing the latest technology in TBS video transmitters! It comes with a built-in graphical OSD and microphone, talks all the protocols and transmits all the power levels! This makes it a perfect companion for any situation where you don't have any OSD, or want to benefit from the simplicity and clarity that the TBS OSD is known for.

TBS packed all the features that they could into the smallest form factor possible. When they set out to make this video transmitter they were looking to make something that would fit all use cases for analog video transmitters ever envisioned. Long range, racing, freestyle, wings, cars. You name it, the VTX will shine in this application! More features are still under development and they can be loaded via the TBS AgentX with the onboard USB port.

The VTX is capable of processing the camera image, so TBS taught it to read barcodes! This means the VTX no longer needs to be transmitting in order to set the channel, and setting channels can be done in the pits. It also means no more guesswork what channel the VTX is on, simply point it at the barcode of your choice and it will move to that channel or power level! There are many more exciting features coming with this technology, stay tuned and barcode on!

CRSF is the defacto standard in FPV and racing drones, so it makes sense that this video transmitter can both understand as well as speak CRSF. For compatibility, the VTX also speaks SA 2.1 and has the teamrace-friendly pitmode feature. PWM controls allow you to use the VTX with any radio and product. For example, you may have it on your RC cars, RC motorcycles or other devices that don't have flight controllers or Crossfire and control the VTX button with a switch or button you have on the radio.

NOTE: An antenna must be installed properly before power is applied to the transmitter. Powering on without a correctly installed antenna may easily burn the transmitter. Power spikes from other components such as ESC's can also damage the transmitter if powered directly from battery voltage. Such damage will not be covered under warranty.

Video Transmission Legality: The use and operation of this product in the USA and many other countries may require a license. Some countries may not allow its use at all. In the USA you must have a HAM radio license to use this transmitter above the 25mW power level. It is the responsibility of the end user to comply with all applicable laws and regulations of their government.

Read More
Read Less
Power 25/100/400/800mW
Input Voltage 6-26V DC
Dimensions 30x23x5.5mm
Connector (Antenna) U.FL socket with SMA cable
Frequency 5.8GHz
Video Format NTSC/PAL
Weight 7g
